HP Designjet 1050c Service Manual

Service Calibrations
5-2
HP DesignJets 1050C and 1055CM Printers Service Manual
Service Calibrations
The Printer has several calibration procedures that must be
performed under certain conditions. Refer to the table below to
determine when calibrations are required.
WARNING REMEMBER THAT CERTAIN CALIBRATIONS ARE
REQUIRED EVEN IF AN ASSEMBLY HAS BEEN
DISASSEMBLED TO GAIN ACCESS TO ANOTHER
ASSEMBLY OR COMPONENT.
NOTE Refer to the following page for the relevant Calibration.
Which Calibrations Need To Be
Done
When Required 12345678♦
Carriage is disassembled or
replaced
No Yes Yes Yes
No
Yes
No
Yes Yes
Electronics Module is
replaced
No No No No No No Ye s Yes
No
Paper-Axis is disassembled
or replaced
Ye s No No No
No Yes No
No No
Platen Assembly is
disassembled or replaced
No No
Ye s
No No Yes No No Yes
Service Station is
disassembled or replaced
No No
Ye s
No No Yes No No No
Drive Roller is
disassembled or replaced
Yes
No No
No
No
Ye s
No
No No
Tubes System (SRK) is
disassembled or replaced
No No No No No No Ye s Yes
No
Banding Problem Yes Yes No No
No
No
No
Ye s No
Misalignment between
Colors
No Ye s No No
No
Ye s
No
Ye s No
Color Accuracy Problem No No No No
No
No
No
No No
Edge Detect Problems No Ye s No No
No
No
No
No No

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
