HP Designjet 1050c Service Manual

Removal and Installation
8-32
HP DesignJets 1050C and 1055CM Printers Service Manual
Back Cover
Refer to Figure 28.
Removal
WARNING Switch off the printer and remove the power cord.
1. Remove the following:
1. "Top Cover" see page 8-31.
2. Remove three T-15 screws (item 1) from the bottom of the back
cover (item 2). Lift the back cover up and remove.
Figure 28: Back Cover
1
C607405
2

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
