HP Designjet 1050c Service Manual

Functional Overview
10-11
HP DesignJets 1050C and 1055CM Printers Service Manual
Snout Wiper
Snout wiper is used to clean the ink accumulation that happens on
the snout of the pen (vertical corner on the interconnect side)
because of wiping operation. This is done to avoid spreading this
ink over the interconnect when replacing the pen and generating ink
shorts between interconnect pads.
Handle and Printable Label
The handle is used to remove and install the PHC. Also, the printer
uses the handle top surface to print and scan some patterns in order
to recognize if:
n PHC is present or not.
n PHC is new or has been used previously.
In addition, there is a built-in mark on the handle (a vertical hole) to
calibrate the service station (Scan-axis) if there is a problem and the
EEROM is erased.

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
