Removal and Installation
8-42
HP DesignJets 1050C and 1055CM Printers Service Manual
Cutter Assembly
Refer to Figure 38 to Figure 40.
Removal
WARNING Switch off the printer and remove the power cord.
1. Remove the following:
1. "Top Cover" see page 8-31.
2. Move the carriage to a position where you can access the printhead
tube connector (refer to Figure 38).
Figure 38: Cutter Assembly
Printhead tube connector
