HP Designjet 1050c

Removal and Installation
8-18
HP DesignJets 1050C and 1055CM Printers Service Manual
Left Hand Trim Assembly
Refer to Figure 16.
Removal
1. Remove 4 screws (Item 1) that attach the Left Hand Trim (Item 2) to
the Printer.
2. Remove the Left Hand Trim (Item 2) from the Printer.
Figure 16: Left Hand Trim
1
C607406
2
