HP Designjet 1050c Service Manual

Parts and Diagrams
7-20
HP DesignJets 1050C and 1055CM Printers Service Manual
Scan-Axis Assemblies
Printer Support
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 C6072-60148 1 Scan-Axis Motor
2 0515-0382 2 Screw
3 C6072-60149 1 Tensioner Assembly (Includes Pulley
Assembly, Pulley Spring, Wedge and
Actuator Arm)
4 0515-0382 2 Screw
5 C6072-60199 1 Cutter Actuator Arm ( (also included
with item 3)
6 C6072-60198 1 Belt (Includes Oil)
7 C6072-60197 1 Encoder Strip
8 0535-0031 2 Nut
9 3050-0026 2 Washer
10 C6072-60158 1 Left Rollfeed Module
11 C6072-60155 1 Right Rollfeed Module
12 C6072-60156 1 Right Rollfeed Brake
13 0624-0704 1 Screw (for item 12)
14 1 Washer (for item 12)
15 C6072-60157 1 Left Rollfeed Brake
16 0624-0704 1 Screw (for item 15)
17 1 Washer (for item 15)
18 2 Screw (for item 15)

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
