HP Designjet 1050c Service Manual

Removal and Installation
8-8
HP DesignJets 1050C and 1055CM Printers Service Manual
Service Station Assembly
Refer to Figure 4.
Removal
WARNING Switch off the printer and remove the power cord.
1. Remove the Printhead Cleaners (Refer to the User Guide).
2. Remove the following
1. "Right Hand Cover" see page 8-4.
3. Disconnect the service station cable from the electronics module out
of position SERVICE STATION.
4. Disconnect the window switch and right door switch cables from
the service station cable.
5. Unclip the Scan-Axis Motor cable from the Service Station.
6. Manually slide the carriage assembly to the middle of the printer.
NOTE Be careful not to drop the service station (item 2) once the
securing fasteners have been removed. Support the service
station throughout the following steps.
7. Between the carriage assembly slider rods there are two holes.
These holes give you access to two T-15 screws (item 3). Remove
the two T-15 screws.
8. Loosen the T-15 screw (item 1) securing the service station to the
side of the printer. This screw is long and does NOT need to be fully
loosened.
NOTE When removing the Service Station, make sure that you release
the Paper-axis Motor cable from the clip that is located on the
Service Station.
9. Lift the service station (item 2) off the loosened screw (item 1) and
standing in front of the printer, slide the assembly towards you.

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
