HP Designjet 1050c Service Manual

Removal and Installation
8-34
HP DesignJets 1050C and 1055CM Printers Service Manual
Encoder Strip
Refer to Figure 30 to Figure 32.
Removal
WARNING Switch off the printer and remove the power cord.
1. Remove the following
1. "Left Hand Cover" see page 8-13.
2. "Right Hand Cover" see page 8-4.
3. "Back Cover" see page 8-32.
CAUTION To prevent damage to the encoder strip, hold it at the ends only.
NOTE Working from the rear of the printer.
NOTE For steps 2 and 3, refer to Figure 30.
2. Remove five 7mm nuts (item 1) from the EMC Cover (item 2).
3. Remove two T-15 screws (item 3) from the EMC Cover and remove
the plate.
Figure 30: Encoder Strip
C607409
1
3
3
2
