HP DesignJets 1050C and 1055CM Printers Service Manual
Drive Roller and ARSS Miscellaneous Parts
NOTE
Items 1 and 3 are not orderable separately. These parts are
included when you order the Drive Roller Assembly on Page 7-28.
Printer Support
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 C6071-40017 1 Drive Roller Gear (See Note Below)
2 0515-2200 2 Screw
3 C6071-40016 1 Drive Roller Bracket (See Note Below)
4 0515-2282 2 Screw
5 C6071-60155 1 ARSS Miscellaneous Parts
6 0515-1743 1 Screw
7 C2847-20018 1 Screw
