HP DesignJets 1050C and 1055CM Printers Service Manual

Electronics Module

Printer Support

Reference

Drawing

HP Part Number Quantity Description/Comments

1 J3113-61001 1 EIO Card

2 C6075-60005 1 Hard Disk Drive

3 C6072-60176 1 DIMM Cover

4 0515-2246 4 Screw

5 C6074-60003 1 DRAM DIMM 16MB

C6074-60004 1 DRAM DIMM 32MB

C6074-60005 1 DRAM DIMM 64MB

6 C6074-60009 1 Firmware DIMM (HP DesignJet 1050C)

C6075-60009 1 Firmware DIMM (HP DesignJet 1055CM)

7 C6072-60171 1 Left Rear Cover (Includes Ferrite and

Clip)

8 0515-2282 1 Screw

9 C6072-60172 1 Right Rear Cover

10 0515-2282 1 Screw

11 C6072-60146 1 Electronics Module

12 0515-0382 4 Screw (for Electronics Module)

- C6072-60177 1 EIO Card Cover
