HP Designjet 1050c Service Manual

Functional Overview
10-12
HP DesignJets 1050C and 1055CM Printers Service Manual
Printer Specifications
Functional Specifications
HP No.80 Supplies Four colors: cyan, magenta, yellow and black.
Printheads: 600 dpi, 12.0 kHz (Cyan, Magenta, Yellow).
12.0 kHz (Black).
Printhead Cleaners: Cyan, magenta, yellow and black.
Ink Cartridges: Cyan, magenta, yellow, each containing 175cc or 350cc of ink
Black contains 350cc of ink.
Paper sizes
Width (carriage axis) Length (paper axis)
Minimum Maximum Minimum Maximum
Roll 610mm 917 mm 600 mm The maximum
length depends on
the amount of
memory the printer
has.
Sheet 210 mm
A/A4
E/A0 210 mm
A/A4
1.6m
Paper types Plain Paper
HP Translucent bond
HP Bright White Inkjet paper
HP Vellum
HP Coated paper
HP Heavy coated paper
HP High-gloss photo paper
HP Matte film
HP Clear film
HP Natural tracing paper
Thin natural tracing paper (greater than 70 g/m
2
)
From time to time, new paper types may become available. For up-to-date information, please contact
your HP dealer or our web site www.designjet-online.hp.com.
Also see the Supplies Source catalog and (in Europe and USA) HP Paper Guide. For alternative names,
HP commercial names and physical characteristics of these paper types, see chapter 3.
Print resolution
by mode setting
Draft
Normal
Best
300 x 300 dpi.
600 x 600 dpi.
600 x 600 dpi. (Color prints)
Addressable 1200 x 600 dpi. (Grayscale prints in Best)

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
