HP Designjet 1050c Service Manual

1
What’s in this Service Manual
This manual contains information necessary to test,
calibrate and service:
- HP DesignJet 1050C (model C6074A)
- HP DesignJet 1055CM (model C6075A)
For information about using these printers, refer to the
corresponding User and Quick Reference Guides.
The procedures described in this manual are to be
performed by HP-qualified Service Personnel only.
DesignJet 1050C/1055CMHP Large-Format Printers

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
