HP Designjet 1050c Service Manual

Service Tests and Utilities
4-25
HP DesignJets 1050C and 1055CM Printers Service Manual
Service Utilities
The following is a list of all internal Service Utilities available in the
Printers. Instructions for entering the Service Utilities menu are
given on Page 4-26.
1 Tubes Purge ⇒ Page 4-28
The purpose of this Service Utility is to Prime the Tubes when a
new Tubes System has been installed.
2 Release Info ⇒ Page 4-32
This Service Utility provides information on the current Firmware
version.
3 Set Asian PS Font ⇒ Page 4-33
The purpose of this Service Utility is to set the Asian Fonts after
replacing the Hard Disk Drive.
4 Printer Model Type ⇒ Page 4-35
The purpose of this Service Utility is to set the correct Printer
Model.
5 Overdrive Cleaning ⇒ Page 4-37
The purpose of this Service Utility is to rotate the Overdrive in order
to clean it.
6 EEROM Utilities ⇒ Page 4-38
The purpose of this Service Utility is to either clear the EEROM or
to test it.
7 Printhead Check ⇒ Page 4-41
This Service Utility allows you to have the Printhead checking
facility ON or OFF.
8 Mon. Mode Baud Sel. ⇒ Page 4-42
This Service Utility allows you to change the Baudrate of the Serial
Port.

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
