HP Designjet 1050c Service Manual

Service Calibrations
5-7
HP DesignJets 1050C and 1055CM Printers Service Manual
3 If media is not loaded, the following message appears on the front
panel and you must load media into the Printer.
NOTE Do NOT use any other type of media apart from HP High Gloss
Photo Paper.
4 The Printer will start to print the Accuracy Calibration Pattern and
the following message will be displayed on the front panel:
5 Once the Accuracy Calibration Pattern is completed, the following
message will be displayed. Remove the pattern from the media and
select "Measure Pattern" and press Enter.
6 Rotate the pattern so that the edge with the arrows points to the
leading edge, and then reload the pattern with the arrow edge print
facing down.
7 The Printer will load the pattern and then measure the alignment
marks using the line sensor on the Carriage Assembly. The
ACCURACY
calibration
Load paper for
ACCURACY
Calibrating
ACCURACY
Calibrating
Recalibrate
Create Pattern
To p
Enter
Back
↑
↓
Press Enter
Measure Pattern
Make Selection

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
