HP Designjet 1050c Service Manual

Service Calibrations
5-23
HP DesignJets 1050C and 1055CM Printers Service Manual
3 If you selected to continue, then the following message appears on
the front panel if media is not loaded. You must load Media in to the
Printer to continue.
WARNING Do NOT use Clear Film, Vellum or Natural Tracing Paper.
4 The Printer will start to print the Alignment Pattern and the
following message will be displayed on the front panel:
5 Once the Pen Alignment calibration is completed, the following
message will be displayed on the front panel:
6 If the calibration fails Perform the Electronic Systems Test ⇒ Page
4-5.
perform this operation
Please, load paper to
and try again
Press ENTER to continue
To p
Enter
Back
↑
↓
Press Enter
Approximate
Aligning printheads
PRINTHEAD ACCESS
time remaining
6 min 30 sec
Press ENTER to continue
Top
Enter
Back
↑
↓
Press Enter
Pen Alignment
calibrated.

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
