HP Designjet 1050c Service Manual

Service Tests and Utilities
4-16
HP DesignJets 1050C and 1055CM Printers Service Manual
appear on the front panel:
In this case, try one of the following:
1 Check all the cables of the APS and make sure they are correctly
connected and are NOT damaged.
2 Check all the tubes of the APS and make sure they are NOT pinched
or damaged.
3 Replace ALL the Ink Cartridges.
4 Replace the complete APS ⇒ Page 8-20.
5 Replace the Electronics Module ⇒ Page 8-25.
WARNING Only replace one component at a time and try the Service Test
again before replacing another component. Using this procedure
you will be able to determine exactly which component failed.
ELECTRONIC SYSTEMS
Possible Failure on:
1. DRAM DIMM(s)
Code: 00XXXX:0000XX
2. Electronics Module
INK PRESSURE SYSTEM
Possible Failure on:
1. APS
Code: 00XXXX:0000XX
2. Electronics Module

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
