Service Tests and Utilities
4-19
HP DesignJets 1050C and 1055CM Printers Service Manual
If the values obtained in the test are less than the Maximum values
in the previous table, then the test has passed.
If the values obtained in the test are greater than the Maximum
values in the previous table, then the test has failed. To resolve the
problem, try the following:
1 Clean the Slider Rods and Apply Oil along the complete axis of the
Slider Rods. After applying the Oil, perform the test again.
2 Check that the Encoder Strip is clean. If necessary, clean Encoder
Strip using a damp cloth.
3 Check that the Tubes System is installed correctly.
4 Check that the Carriage Belt and pulleys are installed correctly.
5 Replace the Scan-Axis Motor Page 8-33.
