HP Designjet 1050c Service Manual

Service Tests and Utilities
4-23
HP DesignJets 1050C and 1055CM Printers Service Manual
3 After initialization, the test will start and the following message will
appear on the front panel:
WARNING In the following step, make sure you do not drop the piece of
paper inside the Drop Detector.
4 When the following message appears, open the Window and insert a
thin piece of paper inside the Drop Detector in order to block it.
Press any Front Panel key once the Drop Detector is blocked.
5 When the following message appears, remove the piece of paper
from inside the Drop Detector and close the Window. Press any
Front Panel key once the Window is closed.
6 The Printer will test the Drop Detector and the following message
will appear on the front panel:
DROP DETECTOR TEST
Detector Test...
Running Drop
and press a FP key
when it is blocked
Block the Drop Detector
paper
Drop Detector
Sensor
close the window
and press a FP key
to continue
Unblock Drop Detector
DROP DETECTOR TEST
Detector Test, ghost d
Running Drop

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
