Ethernet port 26
Table 2-13 Class: SMX_IPProtocolEndpoint
Property name
Property implementation
AddressOrigin How the Address was assigned to this IP Protocol
Endpoint.
•
0 (Unknown)
•
3 (Static)
•
4 (DHCP)
IPv4Address Only initialized if IP interface advertises a valid IPv4
Address.
IPv6Address Only initialized if IP interface advertises a valid IPv6
Address.
IPv6AddressType If ProtocolIFType is 4097 or 4098, then this property is
implemented.
•
3 (Loopback)
•
5 (Link Local Unicast)
•
7 (Embedded IPv4 Address)
IPv6SubnetPrefixLength Unisigned integer. Only initialized if IP interface
advertises a valid IPv6 Address. Its used to describe the
prefix length of the IPv6Address subnet. (Experimental
Schema)
PrefixLength Same as IPv6SubnetPrefixLength. (non-experimental
schema)
Name Opaque Key
SMX scoped instance name.
For example:
HPQ:SMX_IPProtocolEndpoint:<instance_num>
NameFormat Text describing the method to create a unique name for
every IPProtocolEndpoint. For example:
Opaque Key. Unique scoped instance information
HPQ:SMX_IPProtocolEndpoint: concatenated with the
class instance id number.
PrefixLength The prefix length for the IPv6 address of this IP Protocol
Endpoint, if one is defined.
ProtocolIFType 1 (Other)
4096 (IPv4)
4097 (IPv6)
4098 (IPv4/IPv6)
SubnetMask Text representing the mask of the IPv4 address, if
defined, else 0.0.0.0
HP_IPProtocolEndpoint
