Management Processor Lite 385
Table 16-2 Class: SMX_ManagementProcessor
0 (Unknown), when OperationalStatus[0]=0
(Unknown), or when software interface fails
10 (Degraded/Warning), when
OperationalStatus[0]=3 (Degraded)
20 (Major failure), when OperationalStatus[0]=6
(Error)
Note: When a Management processor is disabled
(refer to property EnabledState) HealthState will always
report a state of 5 (OK) so as not to contribute
negatively to overall system status. An MP is disabled
only if the user has manually disabled it via the MP’s
RBSU settings; this is seen as a “normal” condition.
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledState
2 (Enabled) for active MP
3 (Disabled) for inactive/disabled MP
RequestedState 12 (Not Applicable)
EnabledDefault 2 (Enabled)
CreationClassName SMX_ManagementProcessor
Name Opaque instance identifier using “HPQ” as the OrgID.
For example: “HPQ:SMX_ManagementProccessor:1
CIM_ComputerSystem
Dedicated 14 (Management)
ResetCapability 4 (Enabled)
