To set the default status of LUN mapping:
1. Open a Command View VLS session and log in as the administrator. See
“Opening a Command View VLS Session from a Web Browser” on page 143.
2. Click the System tab.
3. Expand Chassis in the navigation tree.
4. Select LUN Mapping in the navigation tree.
5. If this is not your first time changing the setting, select Change Host Access Mode in the task bar.
6. Initially, All Devices is selected, and LUN mapping is disabled.
7. To enable LUN mapping, select User-Defined.
8. Select Apply.
The global default is now set. For every host you add, LUN mapping is automatically enabled
or disabled as you chose.
NOTE:
Both modes allow you to disable a host so that it cannot see any virtual devices regardless of any
other settings.
Mapping LUNs by Device
To map LUNs by device:
1. Select the System tab.
2. Expand Chassis in the navigation tree.
3. Expand LUN Mapping in the navigation tree.
Configuration162
