VLS9000 Single Expansion Disk Array Enclosure Shipping Carton

DescriptionItem

VLS9000 expansion disk array enclosure (1)1

SAS cables (2)2

Power cords (2)3

Printed VLS array installation poster (1)4

1U rack mounting hardware kit (1)5

VLS9000 Node Shipping Carton

Figure 2 Identifying contents of the VLS9000 node shipping carton

DescriptionItem

VLS9000 node1

FC transceivers (2)2

1U rack mounting hardware kit (1) and documentation3

Power cords (2)4

Documentation CD (1) and VLS Quick Restore CD (1)5

Printed VLS node installation poster (1)6
