HP StorageWorks 9000 - Virtual Library System - Racked VLS9000 System (32-Port Connectivity Kit Shown)

Figure 1 Racked VLS9000 system (32-port connectivity kit shown)
.
DescriptionItem
Node 0, primary node1
FC switch 02
FC switch 13
Ethernet Switch 2510–24 (100 Mb)4
Ethernet Switch 2810–24G (1 Gb)5
Base disk array enclosure6
Expansion disk array enclosure7
Expansion disk array enclosure8
Expansion disk array enclosure9
You can install either the VLS9000 20-port or 32-port connectivity kit with the VLS9000-series. (The
VLS9000 7.5 TB and 10 TB systems omit the connectivity kit.) The 20-port connectivity kit includes
two 10-port Fibre Channel switches and two Ethernet switches. The 32-port connectivity kit includes
