DescriptionItemDescriptionItem
array 1, expansion disk array 110array 3, expansion disk array 12
array 1, expansion disk array 011array 3, expansion disk array 03
array 1, base disk array12array 3, base disk array4
array 0, expansion disk array 213array 2, expansion disk array 25
array 0, expansion disk array 114array 2, expansion disk array 16
array 0, expansion disk array 015array 2, expansion disk array 07
array 0, base disk array16array 2, base disk array8
Mounting a Disk Array Enclosure into a Rack
WARNING!
The disk array weighs 33.6 kg (74 lb) full. At least two people are required to lift, move,
and install the disk array.
If only one person is to perform the installation, remove the power modules and hard drives from a
disk array enclosure before installing it, and if possible position it on top of another device or shelf
in the rack to hold it as you attach all the brackets.
CAUTION:
When positioning a disk array enclosure in the rack, ensure the air vents at the front and back of the
enclosure are not blocked.
