SpecificationItem
• Controller enclosure (with drives): 33.6 kg (74 lb)
• Expansion enclosure (with drives): 31.3 kg (69 lb)
Weight
50/60 HzInput frequency
208 to 264 VACInput voltage
• Controller enclosure:
• Spin up: 2.7 A at 220 V, 60 Hz
• Operating: 1.7 A at 220 V, 60 Hz
• Expansion enclosure:
• Spin up: 2.2 A at 220 V, 60 Hz
• Operating: 1.2 A at 220 V, 60 Hz
Input current requirement
• Controller enclosure: 377 W (operating)
• Expansion enclosure: 271 W (operating)
Steady-state maximum input power
• Controller enclosure: 1286 BTU (operating)
• Expansion enclosure: 925 BTU (operating)
Heat dissipation
Fibre Channel Switch 4/10q
SpecificationItem
7.5 x 6.13 x 1.65 in. (19.5 x 15.56 x 4.19 cm) 1U heightDimensions
2.5 lb. (1.1 kg) fully loadedWeight
10 Fibre Channel 4 GB / 2GB / 1GB ports (full-duplex, auto-
negotiating for compatibility with existing 1GB and 2GB devices),
1 Ethernet 10/100 BaseT with RJ45 port
Ports per chassis
• Supports E-port link to another switch
• In-order delivery of frames in all multi-switch and multi-link
configurations
Multi switch fabric
• All ports can assume the following states:
• F_port: Fabric
• FL_port: Fabric loop (public loop)
• E_port: Switch-to-switch (single connection)
• Ports are auto-discovering, self-configuring
Fabric port types
Hot-pluggable, industry-standard SFPs (Small Form Pluggable)Media type
• Shortwave: 500 m (1,640 ft.)
• Longwave: 10 km (6.2 mi.)
Supported SFP types
Specifications296
