Huawei FusionModule2000 Product Description

FusionModule2000 Smart Modular Data Center
Product Description
8 Intelligent Module Management System
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
147
Item
Specifications

Rated voltage: 200–240 V AC

Rated frequency: 50/60 Hz
Power output

Output voltage: 42 - 58 V DC (rated voltage: 53.5 V DC)

Output power of two power module supplies: 2000 W (176–300
V AC); 940 W (linear derating at 85–175 V AC)

Output power of a single power module supply: 1000 W
(176–300 V AC); 470 W (linear derating at 85–175 V AC)
WAN port

Supports two WAN ports. WAN1 is used to connect to the
management system, and WAN2 is used for maintenance. The
ports support autonegotiation of 10/100/1000 Mbit/s
communication rates.

Connect shielded network cables to the WAN ports.
LAN port

Supports two LAN ports, which can be connected to the LAN.
The ports support autonegotiation of 10/100/1000 Mbit/s
communication rates.

Connect shielded network cables to the LAN ports.
RS485 serial port
expansion

Output voltage: 13–15 V DC (rated voltage: 14.5 V DC)

Supports four RS485 ports with the default communications rate
of 9600 bit/s.

COM1–COM3 ports provide 12 V DC power.

The power supply can be switched on or off and is on by
default.
POE expansion
Supports two POE (GE) ports for expansion of the POE bus, and
supports network isolation and ring network.
AIDI expansion
(RJ45)

Output voltage: 13–15 V DC (rated voltage: 14.5 V DC)

Provides five universal AIDI ports for connecting to sensors
such as smoke sensors, water sensors, and NTC sensors. AIDI_1
to AIDI_3 are full-function AIDI ports, and AIDI_4 to AIDI_5
are simplified AIDI ports without type identification.

The power supply can be switched on or off and is on by
default.
DO expansion
(RJ45)

Output voltage: 13–15 V DC (rated voltage: 14.5 V DC)

One DO port. Supports active DO.

The power supply can be switched on or off and is on by
default.
Fault isolation
There are three groups of 12 V ports. A group has a maximum
current of 660 mA, a route has a maximum current of 800 mA, and
the maximum total current is 2 A.
Group 1: 12 V of the AIDI_1 and DO/12V ports
Group 2: 12 V of the AIDI_2, COM1/AIDI_4, and COM3/12V
ports
Group 3: 12 V of the AIDI_3 and COM2/AIDI_5 ports
