Huawei FusionModule2000 Product Description

FusionModule2000 Smart Modular Data Center
Product Description
8 Intelligent Module Management System
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
151
Item
Description
Pin 3
N/A
Pin 4
RS485+
Pin 5
RS485-
Pin 6
N/A
Pin 7
CAN_H
Pin 8
CAN_L
The following provides the AIDI_1, AIDI_2 and AIDI_3 ports pin definitions.

Pins 1, 2, 4, and 5 identify sensor types.

Pin 3 and Pin 8 are power output ports.

Pin 6 and Pin 7 collect sensor data. Pin 7 can detect current type sensors (4–20 mA). Pin 6 and Pin 7
can detect the output status of passive dry contact type sensors. Pin 3 and Pin 7 can detect
temperature sensors.
Table 8-11 AIDI_1, AIDI_2 and AIDI_3 ports pin definitions
Item
Description
Pin sequence
Pin 1
Type_1
Pin 2
Type_2
Pin 3
12 V DC
Pin 4
Type_3
Pin 5
Type_4
Pin 6
DI-
Pin 7
DI+
Pin 8
GND
Indicator
Green
indicator
Power output indicator

Steady on: The 12 V DC output is normal.

Off: No 12 V DC output is provided.
Table 8-12 DO/12V port pin definitions
Item
Description
Pin sequence
Pin 1
N/A
Pin 2
N/A
