8 Intelligent Module Management System
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
152
Item
Description
Pin 3
12 V DC_OUT
Pin 4
N/A
Pin 5
N/A
Pin 6
DO_OUT+
Pin 7
DO_OUT-
Pin 8
GND
Indicator
Green
indicator
Power output indicator

Steady on: The 12 V DC output is normal.

Off: No 12 V DC output is provided.
Table 8-13 USB port pin definitions
Item
Description
Pin sequence
Pin 1
5 V
Pin 2
DM
Pin 3
DP
Pin 4
GND
Indicators
Table 8-14 Indicators on the ECC800-Pro main control module
Indicator
Color
Name
Status
Description
RUN
Green
Running
status
indicator
Steady on
The power supply is normal, the
program is being loaded.
Off
The power supply is abnormal.
Blinking at
long
intervals
The software runs properly (the
indicator blinks at 0.5 Hz, on for
1s and then off for 1s) or the
ECC800-Pro registers with the
NetEco successfully.
Blinking at
short
intervals
The ECC800-Pro does not
register with the NetEco (the
indicator blinks at 5 Hz, on for
0.125s and then off for 0.125s).
ALM
Red
Alarm
Steady on
A system failure alarm is
