v 1.4 — September 2015 Altanium Neo2
58 Test Results Display
8.2.1 Test Results Display
Function Button Description
REWIRE During the test, if the Neo2 finds any thermocouples wired incorrectly,
touch this button, acknowledge to confirmation dialog box to rewire the
thermocouples to the correct location.
AMP, VOLT, WATT, OHM.
240V
These buttons select the information displayed in the associated
column.
SAVE Saves the AMPS, VOLTS, WATTS, OHMS and 220V WATTS readings on all
zones into the LAST column for future reference.
OK Closes the Test Results screen.
Item Description
ZONE The zone number. The operator can view up to 12 zones on one page. If
there are more than 12 zones use the PAGE button to view the rest of the
zones.
TEMP The actual zone temperature being read from the thermocouple in the
mold by the Neo2.
DELAY Used to set a delay time between zones to allow for cooling. The default
is 10 seconds.
TIME The zones elapsed test time.
LAST The AMPS, VOLTS, WATTS, OHMS and 220V WATTS readings that were
saved the last time the diagnostics were ran and the SAVE button was
pressed.
AMPS The actual AMPS, VOLTS, WATTS, OHMS and ADJ WATTS readings of
each tested zone. The column header will change based on the
information being displayed.
EL The earth leakage status for each zone.
SEN The thermocouple sensor test results for each zone.
FUSE The fuse test results for both fuses on each zone.
WIRE The thermocouple wiring test results.
