XPR300 Instruction Manual 809480 147
Connect for Communication
Choose the communication method that is best for your cutting system. There are 3 communication
methods to fully operate the cutting system:
 EtherCAT – Use this method with an EtherCAT-compatible controller. Refer to How to
connect to the plasma power supply with EtherCAT on page 149.

If you use EtherCAT, do not use discrete. You can fully operate the cutting
sy
stem with EtherCAT. Refer to Table 23 on page 148.
 Serial RS-422 and discrete – Use this method with a serial RS-422 and
discrete-compatible controller
.
 Refer to How to connect to the plasma power supply with serial RS-422 on page 151.
 Refer to How to connect to the plasma power supply with discrete on page 154.

If you use serial RS-422, you must also use discrete to fully operate the
cu
tting system. Refer to Table 23 on page 148.
 Wireless (XPR Web Interface) and discrete – Use this method with a wireless-enabled
device and
discrete-compatible controller.
 Refer to How to connect to the plasma power supply with the XPR web interface on
page
166.
 Refer to How to connect to the plasma power supply with discrete on page 154.

If you use wireless, you must also use discrete to fully operate the cutting
sy
stem. Refer to Table 23 on page 148.
For information on signals and protocols, refer to the CNC Communication Protocol for the XPR Cutting
System
(809810).
