Hypertherm XPR300 User Manual

Installation
3
92 809480 Instruction Manual XPR300
Figure 9 – Torch lead collar grounding (detail)
Remove the external panels from the system components
Ground connection – Connect a ground lead
(10 AWG) to the flat terminal on the torch mounting
bracket
WARNING
ELECTRIC SHOCK CAN KILL
Disconnect electric power before doing installation or maintenance. You can
get a serious electric shock if electric power is not disconnected. Electric
shock can seriously injure or kill you.
All work that requires removal of the plasma power supply outer cover or
panels must be done by a qualified technician.
Refer to the Safety and Compliance Manual (80669C) for more safety
information.
