Installation
3
84 809480 Instruction Manual XPR300
Installation steps
Position the system components
Put all system components into position prior to making connections.
Plasma power supply
The XPR300 plasma power supply weighs 590 kg (1,300 lbs). You must use lift equipment to put it
into position. Refer to Table 16. To protect the plasma power supply from drops and damage during
lifting, make sure to balance it evenly and use slow speeds.
Table 16 – Equipment to lift or move the plasma power supply
WARNING
HEAVY EQUIPMENT CAN CAUSE SERIOUS INJURY IF DROPPED – LIFT
CAREFULLY
When lifting or moving the plasma power supply:
• Remove all cables, wires, and other potential obstacles that can get caught on the plasma
power supply.
• Only use lift equipment that can safely lift and support the plasma power supply.
• If you use the lift eye to lift the plasma power supply, lift only the plasma power supply. Do not
exceed the maximum lift-eye rating. See Table 1 on page 30.
• If you use a lift truck, use one with forks that extend along the entire bottom of the plasma
power supply. The bottom of the plasma power supply has lift-truck slots. Make sure to use
them.
• Be gentle when you put the plasma power supply into position. Do not drop it from any height.
Lift truck
Lift truck forks must be long enough to fully support and extend along the entire bottom of the
plasma power supply and rated to hold its weight.
Lift eye
The top of the plasma power supply has a lift eye. Prior to lifting, make sure that the lift equipment
can hold the weight of the plasma power supply.

Hypertherm XPR300 Specifications

General

Cutting Current	300 A
Duty Cycle	100% at 300 A
Technology	X-Definition Plasma
Gas Supply	Oxygen, Nitrogen, Air
Cutting Capacity (Mild Steel)	38 mm (1.5 in)
Severance Capacity (Mild Steel)	75 mm (3 in)
Pierce Capacity (Mild Steel)	50 mm (2 in)
Input Voltage	200–480 V, 3-PH, 50/60 Hz
