Prepare the hoses, cables, and leads
Use the following drawings to identify the correct hoses, cables, and leads prior to installation. For
part numbers and specifications, refer to the Parts List on page 361.
Coolant hose set

The coolant hose set includes 1 supply hose with green bands and
1 return hose with red bands.
Negative lead with strain relief
Pilot arc lead with strain relief
Power cable
CAN cable
Work lead
