Hypertherm XPR300 User Manual

Operation
6
208 809480 Instruction Manual XPR300
Initial checks State (2)
Search for diagnostic codes.
Is there a diagnostic code?
Yes
Diagnose and troubleshoot the problem. Refer to
Diagnostics and Troubleshooting on page 259.
Then, start Initial checks State (2) again.
No
Measure the following:
• Temperatures (main transformers, choppers,
coolant)
• Inlet pressures (gas connect console, torch
connect console)
Are the measurements within the acceptable
range?
No
Diagnose and troubleshoot the problem. Refer to
Diagnostics and Troubleshooting on page 259.
Yes
Wait for process selection by the operator.
Select a process ID.
Continue to Gas purge/pump on State (3) on
page 209.

Hypertherm XPR300 Specifications

General

Cutting Current	300 A
Duty Cycle	100% at 300 A
Technology	X-Definition Plasma
Gas Supply	Oxygen, Nitrogen, Air
Cutting Capacity (Mild Steel)	38 mm (1.5 in)
Severance Capacity (Mild Steel)	75 mm (3 in)
Pierce Capacity (Mild Steel)	50 mm (2 in)
Input Voltage	200–480 V, 3-PH, 50/60 Hz
