Hypertherm XPR300 User Manual

Connect for Communication
4
158 809480 Instruction Manual XPR300
VDC3 board installation (for AVC with RS-422 and discrete-only)
WARNING
ELECTRIC SHOCK CAN KILL
Disconnect electric power before doing installation or maintenance. You can
get a serious electric shock if electric power is not disconnected. Electric
shock can seriously injure or kill you.
All work that requires removal of the plasma power supply outer cover or
panels must be done by a qualified technician.
Refer to the Safety and Compliance Manual (80669C) for more safety
information.
CAUTION
STATIC ELECTRICITY CAN DAMAGE PRINTED CIRCUIT BOARDS
Use precautions when handling printed circuit boards (PCBs) to protect them
from static electricity. Correct PCB handling includes the following steps:
• Store PCBs in anti-static containers.
• Wear a grounded wrist strap when handling PCBs.

Hypertherm XPR300 Specifications

General

Cutting Current	300 A
Duty Cycle	100% at 300 A
Technology	X-Definition Plasma
Gas Supply	Oxygen, Nitrogen, Air
Cutting Capacity (Mild Steel)	38 mm (1.5 in)
Severance Capacity (Mild Steel)	75 mm (3 in)
Pierce Capacity (Mild Steel)	50 mm (2 in)
Input Voltage	200–480 V, 3-PH, 50/60 Hz
