XPR300 Instruction Manual 809480 407
Wiring Diagrams
This section contains the wiring diagrams for the system. When you trace a signal path, or reference
the Parts List or Troubleshooting sections, the following conventions will help you understand the
organization of the wiring diagrams:
 Sheet numbers are located in the lower, right-hand corner of each page.
 References to other pages use the following connection symbol:
Use the sheet number to find the reference sheet. Line up the coordinates A–D on the Y axis and
numbers 1–4 on the X axis of each sheet to find the reference blocks (similar to a road map).
C
Sheet
4-D3
Reference block
Sheet number
Coordinates
