Hypertherm XPR300 User Manual

Installation
3
76 809480 Instruction Manual XPR300
Hoses, cables, and leads
Do not bend the following hoses, cables, and leads beyond a minimum bend radius of 15.25 cm (6 inches):
Torch lead, pilot arc lead, coolant hose set, power cable, CAN cable, 3-gas hose bundle (for the Core gas connect
console), 5-gas hose bundle (for the VWI or OptiMix gas connect console), and gas supply hoses.
The cutting system comes with the cables and leads that connect system components. Refer to the following
sections in the Parts List for part numbers and descriptions:
• Plasma power supply to gas connect console connections on page 393.
• Gas connect console to torch connect console connections on page 395.
• Plasma power supply to CNC connections on page 397.
• Plasma power supply to cutting table connection on page 398.
• Torch connect console to torch receptacle connection on page 399.
Make sure that the hoses, cables and leads are the correct type. Refer to Prepare the hoses, cables, and
leads on page 96.
Make sure that the hoses, cables, and leads are the correct length. Refer to Length requirements for
hoses, cables, and leads on page 60.
Grounding
Make sure that the grounding meets requirements. Refer to Recommended grounding and shielding on
page 67.
Plasma power supply
Gas connect console
Torch connect console
Cutting table
CNC
Torch lead collar

Hypertherm XPR300 Specifications

General

Cutting Current	300 A
Duty Cycle	100% at 300 A
Technology	X-Definition Plasma
Gas Supply	Oxygen, Nitrogen, Air
Cutting Capacity (Mild Steel)	38 mm (1.5 in)
Severance Capacity (Mild Steel)	75 mm (3 in)
Pierce Capacity (Mild Steel)	50 mm (2 in)
Input Voltage	200–480 V, 3-PH, 50/60 Hz
