4.5 Operating method from master device

4-15

4. Operation

4.5 Operating method from master device

Positioning operation: [ST0] [LS0] [ST1] [LS1] signals

Turn [ST0] Signal ON and the actuator drives to the backward end.

Turn [ST1] Signal ON and the actuator drives to the forward end.

Backward signal [ST0]

Backward end signal [LS0]

ELECYLINDER

movement

Backward

Backward end

Backward
