2.3 Installation of Slider type
2-7
2. Installation
Fixing bolt
● Screws and positioning pins to affix the unit should be prepared by the user.
● The use of high-strength bolts of ISO-10.9 or higher is recommended.
● Make sure the internal thread and bolt effective engagement length is 1.5 times the nominal
diameter or more.
● Unless otherwise specified for tightening torque, tighten screws with torque described in the
table below.
For installation of the main unit, apply the torque for “When screw seat is aluminum”.
Fixing bolt
Tightening torque
When screw seat is steel
Tightening torque
When screw seat is aluminum
M8 30.0 N·m 11.5 N·m
