1.3 Options
1-28
1. Specifications
Wireless axis operation specification (Model: WL2)
The wireless axis operation specification includes a built-in wireless circuit board enabling
wireless communication between the ELECYLINDER and the Touch Panel Teaching Pendant.
Specifying WL2 enables operation testing of axis operation (movement to forward and backward
ends, jog operation, inching operation) as well as the operation via wireless communication
enabled with WL. However, the control device is not designed for purposes of automatic
operation.
Be sure to refer to the Precautions for Axis Operation with Wireless Communication.
Certification and self-declaration regarding the wireless function are handled with the wireless
circuit board model name below.
Model name: IABL3826
(Note) Changes from WL to WL2 and from WL2 to WL cannot be performed by the customer.
Please contact us.
Two-circuit power supply specification (Model: TMD2)
It is an option equipped with the stop input to an actuator.
Select this option when it is necessary to cut off only the drive source on ELECYLINDER.
→ Refer to Example for wiring actuator units and motor drive DC power supply
PSA-200.
