1.5 Accessories
1-30
1. Specifications
1.5 Accessories
Power I/O cable
Supplied when length (value other than 0) is specified in the model number cable length.
● The wiring on the opposite side of the connector has not been processed.
● The cable length is available from 1 m to 10 m.
Specify the length in increments of 1 m.
● The following shows a sample model number.
Cable length 1 m → CB-EC-PWBIO010-RB
Cable length 3 m → CB-EC-PWBIO030-RB
Cable length 10 m → CB-EC-PWBIO100-RB
ST0
ST1
RES
* ALM
Note 1 TMD2 is 24V (control)
(Note) Cable in light green and light gray not in use
To Next Page
