6.3 Parameter list
6-5
6. Parameters
6.3 Parameter list
No.
Category
Name Symbol Unit Input range
Default
setting
at shipping
Reference
Page
1 A
Operation
range
adjustment
LIMM mm 0 to 9999.69
Maximum
stroke
6-6
2 A
Auto switch
"LS" signal
detection
range adjustment
INP mm
Actuator Depended
to 9999.99
0.10 6-7
3 C
Home return
direction
change
ORG -
Reverse,
forward
According to
ELECYLINDER
specifications
6-8
4 B
Home position
adjustment
OFST mm 0 to 9999.99
According to
ELECYLINDER
specifications
6-9
5 A
Smooth
accel/decel
setting
MOD0 -
Disabled,
enabled
Disabled 6-10
7 A
Wireless
function setting
RWOF
-
Disabled,
enabled
Disabled 6-11
The categories in the table below indicate whether parameters should be set or not. There
are 3 categories, as follows.
Not displayed on PC compatible software/teaching pendant screen.
A: Check or change the settings based on the usage method.
B: Use as set at shipping, as a rule.
C: Set at shipping in accordance with ELECYLINDER specifications.
Normally, setting is not required.
Caution
No. 1/3/4 default factory settings differ according to ELECYLINDER specifications.
No. 7 Wireless function setting parameter is not displayed on ELECYLINDERs without
wireless circuit boards (no WL, WL2 in the Option model number).
To Next Page
