8.2 Inspection items and schedule
8-3
8. Maintenance and Inspection
8.2 Inspection items and schedule
Follow the maintenance inspection schedule below.
It is assumed that the equipment is operating 8 hours per day.
If the equipment is running continuously night and day or otherwise running at a high operating
rate, inspect more often.
Slider type (EC-S13/S13X/S15/S15X)
Inspection period
External
inspection
Internal
inspection
Greasing
Ball screw Guide
Start of work inspection
○ - - -
1-month inspection
○ - - -
3-month inspection
- - ○ ○
3-month inspection on
- -
Depends on greasing timing
(guideline)
6-month inspection
○ ○
Every 6 months thereafter
○ ○
* Have an inspection on the cushions as well as supplying grease.
Grease supply timing (Guideline)
Maximum operating speed [mm/s]
Grease supply timing (Guideline)
Operation distance Months
0 to 750 or less 1,250 km
12 months
Over 750 to 1500 2,500 km
Over 1500 to 2000 5,000 km
