3.3 Connection arrangement diagram

3-16

3. Wiring

Actuator main unit

[1] Connectivity of ELECYLINDER units to PSA-200 motor power supply

It is available to have six axes at the maximum for connection. The number of axes connectable

should depend on the motor wattage.

→ Refer to Max. units connectable to motor drive DC power supply PSA-200.

Motor power supply cable

Model: CB-EC-PW□□□-RB

Max. cable length: 10 m
