3.2 Electrical specifications
3-2
3. Wiring
3.2 Electrical specifications
Specifications table
Item
Content
EC main unit
controller part
PSA-200
○
Number of
controlled axes
1 axis
○
○
Control power
voltage
24 V DC ±10%
○
Number of max.
axes connectable
6 axes
○
Motor power
voltage
100 V AC type
Single-phase 100 V to 115 V
AC ±10%
200 V AC type
Single-phase 200 V to 230 V
AC ±10%
○
Motor Power
frequency range
50/60 Hz ±5％
○
Max. motor wattage
connectable
100 V AC type 800 W
200 V AC type 1600 W
○
Motor power
capacity
200 W 402 VA
400 W 804 VA
○
Peek max. power
capacity
200 W 1206 VA
400 W 2412 VA
○
Control power
current
320 mA
○
Motor power
voltage output
280 V DC typ
○
Motor power
voltage input
280 V DC typ
○
Control power
capacity
14.5 VA
○
Brake release
power supply
24 V DC ±10％, 85 mA when steady, 875 mA
when in overexcitation
○
Motor power
heating value
200 W 1.7 W
400 W 3.3 W
○
Control power
heating value
8.7 W
