8.5 Greasing method
8-12
8. Maintenance and Inspection
[Recommended grease gun and nozzle]
Grease gun
Grease gun of mounting screw R1/8
Supplier
(Example) GC-57K
Yamada
Corporation
Nozzle Supplier
N type + U type dedicated nozzle
Connect N type to the tip of U type dedicated nozzle, and attach it on
the grease gun to use.
THK
Caution
Supplying too much grease may increase sliding resistance.
This may increase motor load and result in decreased performance.
If the grease enters your eye, immediately see a specialist physician for appropriate care.
After finishing the grease replenishment, wash your hands carefully with water and soap
to rinse the grease off.
N type
U type dedicated nozzle
Grease gun attachment
screw R1/8
U type dedicated nozzle
N type
