Part Names
Intro-19
[Regenerative unit connector]
It is a connector for connectivity to a resistor unit that absorbs the regenerative
current generated when an actuator decelerates and stops.
[Fan unit]
It is a fan for forced air cooling. It should be used by being connected to the fan
connector on the power supply side.
[Status output connector]
It outputs the status of the control power supply (short-circuit / released), the
status of the motor power supply (short-circuit / released) and the alarm status
(H/L levels).
[Status indicator LED]
The status of the control power supply, the status of the motor power supply and
the alarm status should be shown in LED display.
[Power supply connector]
It is a connector for AC power supply connectivity. It provides division input to the
control power supply side and the motor power supply side.
[Grounding terminal]
It is a screw for protection grounding. Do not fail to have it conducted.
[Charge status LED]
It is the LED to show that the internal circuit is being charged.
[Motor power supply connector]
It is a connector to establish connectivity to ELECYLINDER. This supplies power
to the motor.
[Fan unit connector]
It is the connector to establish connectivity to the fan unit. It should be connected
to the fan board on the fan unit side.
