1.2 Mechanical specifications

1-26

1. Specifications

Read a reference for duty with the figured out “Load factor” and “Acceleration/deceleration

time ratio”.

e.g.) The reference for duty when the load factor LF is 80% and the acceleration/deceleration time

ratio tod is 80% should be approximately 75%.

100

0 20 40 60 80 100

加減速度時間比率 t

〔%〕

デュ

ー

テ

ィ

ー

の目安〔

〕

= 60%

= 50%未満

約75%

= 70%

= 80%

= 90%

= 100%

負荷率〔%〕

Load factor [%]

Acceleration/deceleration time ratio t

[%]

Reference for duty [%]

Approximately 75%
