IBM Aptiva Hardware Handbook

92 Installing adapter cards
Installing adapter cards
Before you install an adapter card, you must remove the
system unit cover. For instructions, see page 87.
For some hardware changes, you may need to remove
preinstalled adapter cards. If these adapter cards have
cables attached, disconnect them. (Be sure to notice
where the cables connect to the cards. You will need to
reattach the cables when you reinstall the adapter
cards.)
To install an adapter card:
1. Remove the screw and then the adapter card slot
cover.
Adapter Card
Slots
Adapter Card
Slot Cover
2. Align and insert the adapter card into the adapter
card connector. Insert the screw. (Reverse this
step for card removal.)
3. Reinstall all hardware you removed to install the
adapter card by reversing the removal procedure.
Reconnect cables, if necessary.
Adapter Card Connector
Adapter Card
bi2gntce.bk : bi2gusys.doc Page 92 Saturday, June 3, 1995 6:54 AM

IBM Aptiva Specifications

General

CPU	Intel Pentium
RAM	8 MB to 64 MB
Operating System	Windows 95
Graphics	S3, ATI
Optical Drive	CD-ROM
Ports	Serial, Parallel, PS/2
Expansion Slots	ISA, PCI
