IBM Aptiva Hardware Handbook

Preparing to install adapter cards 111
Video Adapter Cards
When you install a video adapter card you do not need
to reset (move) jumpers on the system board. The built-
in video controller will be disabled automatically.
However, you may need to set jumpers on the video
adapter card. Check the users guide that came with the
card to see if any jumpers need to be set.
Table 12: Adapter card configurations
Adapter card or cards
currently installed:
Adapter card you
are installing:
Action:
None Plug and Play Do not change any settings.
Non–Plug and Play Do not change any settings.
Plug and Play Plug and Play Do not change any settings.
Non–Plug and Play Change settings in the Plug and Play Setup Utility before installing the card. For
instructions on changing the Plug and Play Setup Utility, see the Aptiva Index.
Non–Plug and Play Plug and Play Change settings in the Plug and Play Setup Utility before installing the card. For
instructions on changing the Plug and Play Setup Utility, see the Aptiva Index.
Non–Plug and Play Do not change any settings.
Both Plug and Play and
Non–Plug and Play
Plug and Play Do not change any settings.
Non–Plug and Play Change settings in the Plug and Play Setup Utility before installing the card. For
instructions on changing the Plug and Play Setup Utility, see the Aptiva Index.
bi2gntce.bk : bi2gusy2.doc Page 111 Saturday, June 3, 1995 6:54 AM

IBM Aptiva Specifications

General

CPU	Intel Pentium
RAM	8 MB to 64 MB
Operating System	Windows 95
Graphics	S3, ATI
Optical Drive	CD-ROM
Ports	Serial, Parallel, PS/2
Expansion Slots	ISA, PCI
